Case IH Austoft 9000 Series
Case IH Austoft 9000
Built for Queensland's toughest sugarcane fields, the Austoft 9000 combines a 420 hp FPT Cursor 11 engine with a smart, optimised hydraulic system and factory-installed telematics to deliver higher harvesting capacity at lower operating cost. With exceptional manoeuvrability, ease of maintenance and advanced connectivity, it's engineered to maximise performance across your whole season.
Case IH Austoft 9900
When the ground gets challenging and traction is critical, the Austoft 9900 steps up. Using the same 420 hp FPT engine platform as the Austoft 9000, this track-mounted version offers superior grip and reduced soil compaction — ideal for wet or uneven terrain across the region. Combined with robust serviceability and advanced data connectivity, the Austoft 9900 is a high-performance machine for reliable harvests in demanding conditions.
| Model | Austoft 9000 | Austoft 9900 | |
|---|---|---|---|
| Configuration | |||
| Drive Type | Wheeled | Tracked | |
| Best Suited To | Firm ground, exceptional manoeuvrability | Wet, uneven or challenging terrain — superior traction, reduced soil compaction | |
| Engine | |||
| Engine Model | FPT Cursor 11, 6-cylinder, 11.1 L, Common Rail (up to 2200 bar) | ||
| Power Rating | 420 hp (310 kW) @ 1,600 rpm | ||
| Torque | 2,300 Nm @ 950 rpm | ||
| Emissions | Tier 3 | ||
| Fuel Tank | 620 L (DEF 70 L for Tier 3+) | ||
| Cooling System | Fixed screen radiator with SmartFan auto-reversal | ||
| Hydraulic System | |||
| Pump Type | Intelligent piston pumps with electronic controllers, closed circuit for traction & chopper | Intelligent piston pumps (shared platform) | |
| Harvesting System | |||
| Feed Rate Control | Level 1 & 2 (RPM boost + automatic ground-speed reduction) | ||
| Crop Dividers | 45° design with bolted base shoe & rotating toe | ||
| Side Trim Knife | Standard, reduces adjacent stool damage | ||
| Knockdown Roller | 1,080 mm width, hydraulic/reversible | ||
| Chopper | 4 blades per roller, 380 mm drum, cab-adjustable billet length | ||
| Cleaning System | Anti-vortex cleaning system (30 hp lower power demand) | ||
| Topper | Extended mast, 40% more powerful motor for tall cane | ||
| Elevator | 900 mm width; lighter, higher transport capacity; 360° extractor rotation | ||
| Technology | |||
| AFS Technology | AFS Connect telematics (4G, 3-yr subscription), AFS Autoguidance, PRO700+ monitor | ||
| Chassis | Modular bolted chassis; non-structural bolted hydraulic tanks | ||
| Dimensions & Weight | |||
| Width (mirrors closed) | 3,040 mm | 3,040 mm | |
| Length | 13,930 mm | 13,930 mm | |
| Height | 6,340 mm total; 4,240 mm non-retractable; topper range 890–3,890 mm | 6,340 mm total; 4,240 mm non-retractable; topper range 890–3,890 mm | |
| Weight | 17,360 kg | 17,360 kg – (tracked chassis typically heavier than wheeled equivalent) |
