Farmall B Series
Farmall 25B
With its proven three-cylinder, high-torque diesel engine and easy-to-operate two-range hydrostatic transmission, this purpose-built compact tractor is perfect for pulling trailers and light implements, mowing, and front loader work.
- Standard 2000 RPM Mid PTO: For optional height-adjustable 60” mid-mount mower that produces a smooth and beautiful cut.
- Hydrostatic Transmission: Maximises ease of use with effortless, clutch-less and instant speed and directional changes with a simple push of the pedals.
Farmall 35B
The mighty 38 hp helper for the serious lifestyle farmer. With its fuel-efficient 4-cylinder engine and 1,385 kg dry weight, the Farmall 35B takes lifestyle farming to a whole new level. With a host of standard features normally found on larger tractors, it’s no wonder the Farmall 35B is the most popular model in the Case IH lifestyle range. Available with Hydrostatic or Synchro transmission options.
Farmall 50B
With its robust 2.5L four-cylinder diesel engine and a choice of either a three-range hydrostatic or 16x16 synchro transmission, the Farmall 50B is a versatile and powerful compact tractor. It is well-suited for a wide range of tasks, from demanding loader work to operating various implements, making it an excellent choice for larger lifestyle farms and professional applications.
Farmall 60B
As the most powerful tractor in the Farmall B series, the Farmall 60B is designed to tackle the most demanding jobs. Its turbocharged engine delivers effortless power, and it comes with a host of impressive features as standard, including two sets of hydraulic remotes and a three-speed PTO.
| Model | Farmall 25B | Farmall 35B | Farmall 50B | Farmall 60B |
|---|---|---|---|---|
| Engine | ||||
| Gross Power (hp) | 27 | 38 | 47 | 57 |
| Cylinders / Capacity | 3-cyl 1.32 L | 4-cyl 1.76 L | 4-cyl 2.5 L | 4-cyl 2.5 L |
| Aspiration | Naturally aspirated | Naturally aspirated | Naturally aspirated | Naturally aspirated |
| Max Torque (Nm) | 79 | 103 | 140 | 170 |
| Fuel Tank (L) | 25 | 33 | 36 | 80 |
| Power Take Off | ||||
| PTO Type | Independent | Independent electro-hydraulic | Independent | Independent |
| Rear PTO Speed | 540 rpm | 540 rpm | 540 rpm | 540 rpm |
| PTO Power | – | 21.6–23.1 kW (29–31 hp) | – | – |
| Best Suited To | Light PTO implements | General PTO implements | Slashers, mowers, post hole diggers | Slashers, spreaders, augers, pasture equipment |
| Transmission | ||||
| Type | 3-range hydrostatic | 12-speed shuttle or 3-range hydrostatic | 12 x 12 partially synchronised shuttle | 12 x 12 synchronised shuttle |
| Control | Twin-pedal | – | – | – |
| Brakes | Wet disc | Wet disc | Wet disc | Wet disc |
| Diff Lock | Mechanical rear | Mechanical rear | Mechanical rear | Mechanical rear |
| Hydraulics | ||||
| System Type | Open-centre | Open-centre | Open-centre | Open-centre |
| Implement Flow | – | 31.0 L/min | High-flow | High-capacity |
| Steering Flow | – | Up to 20.8 L/min | – | – |
| Remote Valves | Mid-mount, optional | Loader/implement compatible | Loader/implement compatible | Loader/implement compatible |
| 3-Point Hitch | ||||
| Category | Category 1 | Category 1 | Category 1 | Category 1/2 |
| Rear Lift (Ball Ends) | – | 819 kg | – | – |
| Control Type | Position control | Position control | Position control | Position control |
| Axle / Drive | ||||
| Drive Type | 4WD (MFWD) | 4WD (MFWD) | 4WD (MFWD) | 4WD (MFWD) |
| Steering | Hydrostatic power | Hydrostatic power | Hydrostatic power | Hydrostatic power |
| Dimensions & Weight | ||||
| Wheelbase (mm) | 1,500 | 1,676 | 1,758 | 2,047 |
| Length (mm) | 2,660 | 3,023 | 3,556 | 3,556 |
| Height (mm) | 2,370 | 2,311 (ROPS) | 2,447 | 2,650 (Cab) |
| Weight (kg) | ~730 base | 1,451 operating | 1,680 Hydro / 1,650 Mech | 2,165 ROPS / 2,370 Cab |
