Farmall M Series
Farmall 90M
Design beyond comparison — power meets precision
The Farmall 90M ActiveDrive 4 brings together power and efficiency in a package built for the serious farmer. At its heart is the powerful S8000 engine, 4-cylinder, turbocharged and intercooled — delivering high torque with the ActiveDrive 4 semi-powershift transmission for smooth, on-the-run gear changes and instant power at key working speeds.
With electro-hydraulic power shuttle, automatic 4WD, automatic differential lock, and up to 5,200 kg of hydraulic lift capacity, the Farmall 90M is engineered to handle the toughest field and PTO-driven tasks with ease.
Comfort takes centre stage too, with a spacious air-conditioned cab, air-suspension seat, and ergonomic controls — designed to keep you performing at your best, no matter how long the day.
Farmall 100M
A true multi-tool for the toughest challenges.
The Farmall 100M ActiveDrive 4 sits right in the sweet spot of the range, pairing serious mid-tier power with the same meticulous engineering found across the Farmall M lineup. At its heart is the powerful S8000 engine — 4-cylinder, turbocharged and intercooled — delivering high torque with the ActiveDrive 4 semi-powershift transmission for smooth, on-the-run gear changes and instant power at key working speeds.
With electro-hydraulic power shuttle, automatic 4WD, automatic differential lock, and up to 5,200 kg of hydraulic lift capacity, the Farmall 100M is engineered to handle the toughest field and PTO-driven tasks with ease.
Comfort takes centre stage too, with a spacious air-conditioned cab, air-suspension seat, and ergonomic controls — designed to keep you performing at your best, no matter how long the day.
Farmall 110M
A true multi-tool for the toughest challenges.
The Farmall 110M ActiveDrive 4 tops the Farmall M lineup, bringing together maximum power and efficiency in a package built for the serious farmer. At its heart is the powerful S8000 engine — 4-cylinder, turbocharged and intercooled — delivering high torque with the ActiveDrive 4 semi-powershift transmission for smooth, on-the-run gear changes and instant power at key working speeds.
With electro-hydraulic power shuttle, automatic 4WD, automatic differential lock, and up to 5,200 kg of hydraulic lift capacity, the Farmall 110M is engineered to handle the toughest field and PTO-driven tasks with ease.
Comfort takes centre stage too, with a spacious air-conditioned cab, air-suspension seat, and ergonomic controls — designed to keep you performing at your best, no matter how long the day.
| Model | Farmall 90M | Farmall 100M | Farmall 110M |
|---|---|---|---|
| Engine | |||
| Maximum Power | 88 hp | 98 hp | 110 hp |
| Cylinders / Aspiration | 4 / Turbo / Intercooler | 4 / Turbo / Intercooler | 4 / Turbo / Intercooler |
| Displacement | 3,908 cm³ | 3,908 cm³ | 3,908 cm³ |
| Max Torque | 356 Nm | 390 Nm | 430 Nm |
| Torque @ Engine RPM | 1,400 rpm | 1,400 rpm | 1,400 rpm |
| Fuel Tank | 145 L | 145 L | 145 L |
| Emissions | Tier III | Tier III | Tier III |
| Power Take Off | |||
| Control Type | Electro-hydraulic | Electro-hydraulic | Electro-hydraulic |
| PTO Speeds | 540 / 540E / 1000 | 540 / 540E / 1000 | 540 / 540E / 1000 |
| Auto PTO Feature | Standard | Standard | Standard |
| Transmission | |||
| Type | ActiveDrive 4 Semi-Powershift | ActiveDrive 4 Semi-Powershift | ActiveDrive 4 Semi-Powershift |
| Gears | 16F / 16R (32x32 creeper opt) | 16F / 16R (32x32 creeper opt) | 16F / 16R (32x32 creeper opt) |
| Power Shuttle | Electro-hydraulic, standard | Electro-hydraulic, standard | Electro-hydraulic, standard |
| Auto 4WD / Diff Lock | Standard | Standard | Standard |
| Hydraulics | |||
| Draft Control | Electronic | Electronic | Electronic |
| Hydraulic Outlets | 6 | 6 | 6 |
| 3-Point Linkage | |||
| Lift Capacity | 5,200 kg | 5,200 kg | 5,200 kg |
| Hydraulic Top Link | Optional | Optional | Optional |
| Cab & Comfort | |||
| Cab / Air Conditioning | Standard | Standard | Standard |
| Seat / Radio | Air suspension seat, Bluetooth | Air suspension seat, Bluetooth | Air suspension seat, Bluetooth |
| Dimensions & Weight | |||
| Wheelbase | 2,519 mm | 2,519 mm | 2,519 mm |
| Overall Length | 4,496 mm | 4,496 mm | 4,496 mm |
| Maximum Height | 2,604 mm | 2,631 mm | 2,657 mm |
| Front Track | 1,560–2,002 mm (13.6R24) | 1,560–2,002 mm (14.9R24) | 1,530–2,032 mm (360/70R28) |
| Rear Track | 1,588–2,136 mm (16.9R34) | 1,588–2,090 mm (18.4R34) | 1,678–2,090 mm (420/85R38) |
| Total Weight | 4,220 kg | 4,220 kg | 4,220 kg |
| Tyres (Front / Rear) | 13.6R24 / 16.9R34 | 440/65R24 / 540/65R34 | 440/65R24 / 540/65R34 |
