Farmall JX Series
Farmall JX75
Versatile, agile, powerful — built for the next generation of farming.
The Farmall JX75 is powered by the proven S8000 Series Tier 3 turbocharged engine, carefully tuned for optimum fuel efficiency and maximum power. With up to 30% torque rise, it delivers fewer gear changes and greater efficiency across loader work, field operations, and everyday yard tasks.
A choice of transmissions — including 12 x 12 Synchro Shuttle or 12 x 12 Hydraulic Powershuttle — gives you smooth, clutchless direction changes ideal for loader work and repetitive forward-reverse tasks. Backed by high-capacity hydraulics and a robust 3-point hitch, the Farmall JX75 is built to put power exactly where you need it most.
Farmall JX90
Versatile, agile, powerful — built for the next generation of farming.
The Farmall JX90 is powered by the proven S8000 Series Tier 3 turbocharged engine, carefully tuned for optimum fuel efficiency and maximum power. With up to 30% torque rise, it delivers fewer gear changes and greater efficiency across loader work, field operations, and everyday yard tasks.
A choice of transmissions — including 12 x 12 Synchro Shuttle or 12 x 12 Hydraulic Powershuttle — gives you smooth, clutchless direction changes ideal for loader work and repetitive forward-reverse tasks. Backed by high-capacity hydraulics and a robust 3-point hitch, the Farmall JX90 is built to put power exactly where you need it most.
Farmall JX100
Versatile, agile, powerful — built for the next generation of farming.
The Farmall JX100 is powered by the proven S8000 Series Tier 3 turbocharged engine, carefully tuned for optimum fuel efficiency and maximum power. With up to 30% torque rise, it delivers fewer gear changes and greater efficiency across loader work, field operations, and everyday yard tasks.
A choice of transmissions — including 12 x 12 Synchro Shuttle or 12 x 12 Hydraulic Powershuttle — gives you smooth, clutchless direction changes ideal for loader work and repetitive forward-reverse tasks. Backed by high-capacity hydraulics and a robust 3-point hitch, the Farmall JX100 is built to put power exactly where you need it most.
Farmall JX110
An entirely new level of power and performance.
Topping the Farmall JX range, the Farmall JX110 is powered by the proven S8000 Series Tier 3 turbocharged engine, carefully tuned for optimum fuel efficiency and maximum power. With up to 30% torque rise, it delivers fewer gear changes and greater efficiency across loader work, field operations, and everyday yard tasks.
A choice of transmissions — including 12 x 12 Synchro Shuttle or 12 x 12 Hydraulic Powershuttle — gives you smooth, clutchless direction changes ideal for loader work and repetitive forward-reverse tasks. Backed by high-capacity hydraulics and a robust 3-point hitch, the Farmall JX110 is built to put maximum power exactly where you need it most.
| Model | JX75 | JX90 | JX100 | JX110 |
|---|---|---|---|---|
| Engine | ||||
| Rated Power | 56 kW (75 hp) | 66 kW (88 hp) | 73 kW (98 hp) | 81 kW (110 hp) |
| Displacement | 3,908 cm³ | 3,908 cm³ | 3,908 cm³ | 3,908 cm³ |
| Cylinders | 4-cyl Turbo | 4-cyl Turbo | 4-cyl Turbo | 4-cyl Turbo |
| Max Torque | 298 Nm | 356 Nm | 390 Nm | 430 Nm |
| Torque @ RPM | 1,400 rpm | 1,400 rpm | 1,400 rpm | 1,400 rpm |
| Fuel Tank | 110 L | 110 L | 110 L | 110 L |
| Power Take Off | ||||
| PTO Speeds | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
| Ground Speed PTO | Standard | Standard | Standard | Standard |
| Transmission | ||||
| Standard Options | 12x12 Synchro / Powershuttle | 12x12 Synchro / Powershuttle | 12x12 Synchro / Powershuttle | 12x12 Synchro / Powershuttle |
| Optional Creeper | 20x12 available | 20x12 available | – | – |
| Axle / Drive | ||||
| Configuration | 2WD / 4WD | 2WD / 4WD | 2WD / 4WD | 2WD / 4WD |
| Steering Angle (2WD/4WD) | 55° / 40° | 55° / 40° | 55° / 40° | 55° / 40° |
| Hydraulics | ||||
| Pump Flow | 51.7 L/min | 51.7 L/min | 51.7 L/min | 51.7 L/min |
| Steering/Services Pump | 29 L/min | 28 L/min | 28 L/min | 28 L/min |
| Remote Valves | 2 std, up to 3 | 2 std, up to 3 | 2 std, up to 3 | 2 std, up to 3 |
| 3-Point Linkage | ||||
| Max Lift (Ball Ends) | 3,565 kg | 3,565 kg | 3,565 kg | 3,565 kg |
| Lift @ 610mm Behind | 2,700 kg | 2,700 kg | 2,700 kg | 2,700 kg |
| Dimensions & Weight | ||||
| Wheelbase (2WD/4WD) | 2,468 / 2,402 mm | 2,468 / 2,402 mm | 2,488 / 2,422 mm | – / 2,422 mm |
| Overall Length (2WD/4WD) | 3,923 / 3,998 mm | 3,941 / 4,044 mm | 3,991 / 4,115 mm | – / 4,115 mm |
| Overall Height (Cab/ROPS) | 2,604 / 2,719 mm | 2,604 / 2,719 mm | 2,631 / 2,746 mm | 2,657 / 2,772 mm |
| Track Width (Min/Max) | 1,500–2,000 mm | 1,500–2,000 mm | 1,600–2,000 mm | 1,600–2,000 mm |
| Rear Tyres | 16.9R30 | 18.4R34 | 16.9R38 | 16.9R38 |
| Weight ROPS (2WD/4WD) | 3,000 / 3,450 kg | 3,000 / 3,450 kg | 3,250 / 3,650 kg | – / 3,650 kg |
| Weight Cab (2WD/4WD) | 3,300 / 3,600 kg | 3,300 / 3,700 kg | 3,500 / 3,900 kg | – / 3,900 kg |
