Farmall JXM Series
Farmall JXM 55
More power. More options. More comfort.
The Farmall JXM 55 is powered by the proven FPT (IVECO S8000) 3-cylinder turbocharged Tier III engine, delivering reliable power and class-leading torque rise for its size. Its simple, robust design means trouble-free, long-life working with reduced maintenance requirements — perfect as a utility tractor or the flagship of a small farming operation.
The Farmall JXM 55 comes standard with a Synchro-Mechanical forward/reverse shuttle transmission, giving you straightforward, dependable control for everyday yard and field work.
Backed by a 60 L/min hydraulic system, up to three rear remote valves, and a 3-point hitch rated to 2,500 kg, the Farmall JXM 55 delivers solid manoeuvrability and stability for smaller-scale operations.
Farmall JXM 65
More power. More options. More comfort.
The Farmall JXM 65 is powered by the proven FPT (IVECO S8000) 3-cylinder turbocharged and intercooled Tier III engine, delivering class-leading torque and reliable power day in, day out. Its simple, robust design means trouble-free, long-life working with reduced maintenance requirements.
A 12 x 12 Mechanical Synchroshuttle transmission comes standard, with an optional Hydraulic Powershuttle available for smooth, clutchless direction changes — ideal for repetitive forward-reverse loader work.
Backed by a 60 L/min hydraulic system, up to three rear remote valves, and a 3-point hitch rated to 2,500 kg, the Farmall JXM 65 delivers outstanding manoeuvrability and stability for everyday jobs on the property.
Farmall JXM 75
More power. More options. More comfort.
The Farmall JXM 75 is powered by the proven FPT (IVECO S8000) 3-cylinder turbocharged and intercooled Tier III engine, delivering class-leading torque and reliable power day in, day out. Its simple, robust design means trouble-free, long-life working with reduced maintenance requirements.
A choice of transmissions — including 12 x 12 Mechanical Synchroshuttle with optional 20 x 20 creeper, or an optional Hydraulic Powershuttle — gives you the flexibility to match the tractor to your operation, whether that's loader work, PTO-driven implements, or specialist applications like vegetable planting and harvesting.
Backed by a 60 L/min hydraulic system, up to three rear remote valves, and an optional 3,500 kg-rated 3-point hitch, the Farmall JXM 75 delivers outstanding manoeuvrability and stability for the toughest jobs on the property.
Farmall JXM 90
More power. More options. More comfort.
Topping the JXM range, the Farmall JXM 90 is powered by the proven FPT (IVECO S8000) 4-cylinder turbocharged and aftercooled Tier III engine, delivering class-leading torque and reliable power day in, day out. Its simple, robust design means trouble-free, long-life working with reduced maintenance requirements.
A choice of transmissions — including 12 x 12 Mechanical Synchroshuttle with optional 20 x 20 creeper, or an optional Hydraulic Powershuttle — gives you the flexibility to match the tractor to your operation, whether that's loader work, PTO-driven implements, or specialist applications like vegetable planting and harvesting.
Backed by a 60 L/min hydraulic system, up to three rear remote valves, and an optional 3,500 kg-rated 3-point hitch, the Farmall JXM 90 delivers outstanding manoeuvrability and stability for the biggest jobs in the range.
| Model | JXM 55 | JXM 65 | JXM 75 | JXM 90 |
|---|---|---|---|---|
| Engine | ||||
| Rated Power @ 2,300rpm | 41 kW (55 hp) | 48 kW (65 hp) | 56 kW (75 hp) | 65.7 kW (88 hp) |
| Cylinders / Aspiration | 3-cyl Turbo | 3-cyl Turbo Intercooled | 3-cyl Turbo Intercooled | 4-cyl Turbo Aftercooled |
| Displacement | 2.9 L | 2.9 L | 2.9 L | 3.9 L |
| Max Torque @ 1,400rpm | 220 Nm | 270 Nm | 306 Nm | 340 Nm |
| Torque Rise | 30% | 30% | 32% | 25% |
| Fuel Tank (Main + Aux) | 60 + 40 L | 60 + 40 L | 60 + 40 L | 90 L |
| Power Take Off | ||||
| PTO Power @ Rated Speed | 37 kW (49 hp) | 43 kW (57 hp) | 50 kW (67 hp) | 57.0 kW (76 hp) |
| PTO Speeds | 540/540E | 540/540E | 540/540E | 540/540E |
| PTO Type | Independent, standard | Independent, standard | Independent, standard | Independent, standard |
| Transmission | ||||
| Standard | Synchro-Mechanical shuttle | 12x12 Mechanical Synchroshuttle | 12x12 Mechanical Synchroshuttle | 12x12 Mechanical Synchroshuttle |
| Power Shuttle | Optional | Optional | Optional | Optional |
| Creeper Option | – | – | 20x20 optional | 20x20 optional |
| Road Speed (Min/Max) | 1.56–32.05 km/h | 1.56–33.23 km/h | 1.56–34.4 km/h | 1.72–35.8 km/h |
| Creeper Speed | – | – | 0.27 km/h | 0.29 km/h |
| Hydraulics | ||||
| Main Pump Flow | 60 L/min | 60 L/min | 60 L/min | 60 L/min |
| Steering Pump (MS/PS) | 26/31 L/min | 26/31 L/min | 26/31 L/min | 26/31 L/min |
| Remote Valves (Max) | 3 | 3 | 3 | 3 |
| 3-Point Linkage | ||||
| Category | I–II | I–II | I–II | I–II |
| Max Lift (Ball Ends) | 2,500 kg | 2,500 kg | 3,500 kg (optional) | 3,500 kg (optional) |
| Axle / Brakes | ||||
| Front Axle | 4WD |
