Case IH Farmall Subcompact 25SC
OVERVIEW
Big capability. Compact footprint.
Designed for lifestyle properties, hobby farms and acreage owners, the Farmall 25SC combines easy operation, compact dimensions and proven Case IH reliability to help you accomplish more every day.
Front Loader L320S
- Safe Working Load (SWL): 218 kg
- Max Lift Height: 1830 mm
- Max Hinge Pin Height: 1650 mm
- Mechanical Self Leveling: Standard
- 4 In 1 Bucket with third service integrated into mid mount valve
MW60S Mower
- Mounting Point: Mid Mount
- Cutting Width: 1520 mm
- Side Disc Charge Stamped Deck
BH80S Backhoe
- Bucket Size: 9 inches
- Digging Depth: 2020 mm
- Swing Arc: 135 degrees
- Shipping Weight: 321 kg
Great for
- Lifestyle properties and acreage
- Grounds care and mowing
- Light landscaping and loader work
- Small‑block farming and chores
Highlights
- Yanmar 1.26 L, 3‑cyl diesel (Stage V)
- 4WD, wet multi‑disc brakes
- Cat. 1 three‑point hitch
- Flat "Clear‑Thru" operator platform
- ROPS with fold‑down capability
Why Farmall 25SC
- Easy hydrostatic control
2‑range HST with dual‑pedal layout and cruise control for steady mowing or towing.
- Electro‑hydraulic PTO
Push‑button rear and mid‑PTO (540 / 2,000 rpm) for mowers, slashers and more.
- True 4WD confidence
Standard mechanical front‑wheel drive and diff‑lock for slippery or hilly ground.
- Compact and capable
Only ~1.19 m wide with a tight turning circle for sheds and garden access.
- Low‑maintenance design
Simple, robust layout with excellent service access.
Specs
ENGINE 24.7 HP Diesel
NO. OF CYLINDERS 3 Cylinders
FUEL TANK CAPACITY 25L
DRIVE TYPE 4WD
TRANSMISSION 2-Range Hydrostatic
MAX FORWARD SPEED 14.7 km/h
PTO 540 Rear / 2000 Mid RPM
PTO TYPE Independent Electro-Hydraulic
3-POINT HITCH Category 1
DIMENSIONS (L × W × H) 2473 × 1187 × 2220 mm
WHEELBASE 1425 mm
WEIGHT 655 kg
