Case IH Optum Series
Optum 270
The Optum 270 delivers 270 hp from a powerful 6-cylinder 6.7 L FPT engine, fully Stage V compliant with HI-eSCR2 exhaust after-treatment. Paired with CVTDrive continuously variable transmission and high-capacity hydraulics, it's built for demanding broadacre and row crop operations that need serious pulling power.
Optum 300
The Optum 300 delivers 300 hp from a powerful 6-cylinder 6.7 L FPT engine, fully Stage V compliant with HI-eSCR2 exhaust after-treatment. Paired with CVTDrive continuously variable transmission and high-capacity hydraulics, it's built for demanding broadacre and row crop operations that need serious pulling power.
Optum 340
Topping the range, the Optum 340 delivers 340 hp from a powerful 6-cylinder 6.7L FPT engine, fully Stage V compliant with HI-eSCR2 exhaust after-treatment. Paired with CVTDrive continuously variable transmission and high-capacity hydraulics, it's built for the biggest broadacre and row crop jobs that demand maximum pulling power.
| Model | Optum 270 | Optum 300 | Optum 340 |
|---|---|---|---|
| Engine | |||
| Rated Power | 270 hp | 300 hp | 340 hp |
| Max Power | 288 hp | 313 hp | 340 hp |
| Cylinders / Capacity | 6 / 6,728 cm³ | 6 / 6,728 cm³ | 6 / 6,728 cm³ |
| Max Torque | 1,194 Nm @ 1,400 rpm | 1,282 Nm @ 1,400 rpm | 1,398 Nm @ 1,400 rpm |
| Torque Rise | 32% | 28% | 23% |
| Emissions | Stage V, HI-eSCR2 | Stage V, HI-eSCR2 | Stage V, HI-eSCR2 |
| Fuel Tank / AdBlue | 630 L / 96 L | 630 L / 96 L | 630 L / 96 L |
| Power Take Off | |||
| PTO Speeds | 540/540E/1,000/1,000E | 540/540E/1,000/1,000E | 540/540E/1,000/1,000E |
| Front PTO Speeds | 1,000/1,000E at 1,886/1,585 rpm | 1,000/1,000E at 1,886/1,585 rpm | 1,000/1,000E at 1,886/1,585 rpm |
| Transmission | |||
| Type | CVTDrive, 50kph ECO | CVTDrive, 50kph ECO | CVTDrive, 50kph ECO |
| Diff Lock | Multi-disc wet plate w/ management | Multi-disc wet plate w/ management | Multi-disc wet plate w/ management |
| Hydraulics | |||
| Max Pump Flow / Pressure | 220 L/min / 215 bar | 220 L/min / 215 bar | 220 L/min / 215 bar |
| Rear Remote Valves | 5 electrical | 5 electrical | 5 electrical |
| Mid-Mount Valves | 3 electrical | 3 electrical | 3 electrical |
| 3-Point Hitch | |||
| Category | Cat III / IVN | Cat III / IVN | Cat III / IVN |
| Rear Lift Capacity | 11,058 kg | 11,058 kg | 11,058 kg |
| Front Hitch Lift Capacity | 6,016 kg | 6,016 kg | 6,016 kg |
| Dimensions & Weight | |||
| Wheelbase | 2,995 mm | 2,995 mm | 2,995 mm |
| Max Length | 5,825 mm | 5,825 mm | 5,825 mm |
| Max. permissible weight front single / dual wheels / rear | 7,500 / 6,500 / 11,600 kg | 7,500 / 6,500 / 11,600 kg | 7,500 / 6,500 / 11,600 kg |
