Case IH Round Baler Series
Case IH RB455 Round Baler
The RB455 variable chamber round baler delivers high-capacity, consistent bale formation across hay, straw, and silage. With a 2.05 m high-speed pick-up, dual auger feeding, and an optional rotor cutter with 15 knives, it maintains strong crop flow even in heavy windrows. Endless belts and dual density cylinders produce tightly packed, uniform bales up to 150 cm, ensuring better storage, transport efficiency, and preserved feed quality. Built for mixed farmers and contractors handling medium to large operations, the RB455 offers flexibility, ease of operation, and minimal downtime with simple ground-level servicing.
Case IH RB465 Round Baler
The RB465 is built for high-output baling where larger bale size and efficiency matter. With a 2.05 m high-capacity pick-up and dual auger feeding system, it handles heavy windrows with ease, maintaining smooth crop flow across hay, straw, and silage. Endless belts and dual density cylinders deliver uniform, tightly packed bales up to 180 cm, improving transport efficiency and feed quality across varied conditions. Ideal for contractors and larger operations pushing higher daily output, the RB465 reduces handling time with bigger, heavier bales while maintaining consistent density.
Case IH RB456 HD Pro Round Baler
The RB456 HD Pro is built for high-density baling across silage, hay, and straw, even in tough conditions. A heavy-duty driveline, 2.3 m high-capacity pick-up, and V-shaped rotor deliver consistent crop flow, while the active drop floor reduces blockages in heavy windrows. With up to 25 knives and in-cab density control, it produces tightly packed, uniform bales up to 165 cm. Ideal for contractors and larger operations, the RB456 HD Pro delivers reliable output with minimal downtime and simple in-cab control.
RB466 HD Pro Round Baler
Case IH RB466 HD Pro Round Baler
The RB466 HD Pro is engineered for high-output baling in the toughest conditions, from dense silage to heavy straw windrows. Built with a heavy-duty driveline, 2.3 m high-capacity pick-up, and V-shaped rotor, it maintains consistent crop flow while the active drop floor reduces blockages. With up to 25 knives and in-cab density control, it delivers tightly packed, uniform bales up to 190 cm — the largest bale size in the Case IH round baler range. Ideal for demanding contractors and large-scale operations, it maximises daily output with minimal downtime.
| Model | RB455 | RB465 | RB456 HD Pro | RB466 HD Pro |
|---|---|---|---|---|
| Bale Dimensions | ||||
| Bale Diameter | 90–150 cm | 90–180 cm | 90–165 cm | 90–190 cm |
| Bale Width | 120 cm | |||
| Tractor Requirements | ||||
| Min. PTO Power (Feeder) | 48 kW (65 hp) | 52 kW (70 hp) | 74 kW (100 hp) | |
| Min. PTO Power (Rotor/Cutter) | 52 kW (70 hp) | 60 kW (80 hp) | 88 kW (120 hp) | |
| PTO Speed | 1,000 rpm | |||
| Overall Protection | Cut-out clutch in PTO | Cut-out clutch | ||
| Hydraulic Outlets Required | – | 2 | ||
| Pick-Up | ||||
| Effective Width | 2.05 m (DIN 11220 = 2.35 m) | 2.3 m | ||
| Tine Bars | 5 | |||
| Windguard Type | Roller | |||
| Overload Protection | Shearbolt | Radial pin clutch | ||
| Feeder & Crop Cutter | ||||
| Rotor Type | W-configuration rotor | "V" shape rotor, 520 mm diameter | ||
| Feeding System | Rotor Feeder or Rotor Cutter (15 knives) | Rotor Feeder or Rotor Cutter (15 knives) | Rotor Feeder or Rotor Cutter (13 or 25 knives) | |
| Drop Floor | Hydraulically operated, manual rotor reversing | Active drop floor, standard | ||
| Knife Protection | Spring reset | Hydraulic | ||
| Bale Formation & Wrapping | ||||
| Number of Belts | 4 belts (premium endless belt + rollers + 3 pivoting rollers) | 4 × 273 mm endless belts | ||
| Density Control | Dual density system, standard | In-cab dual density hydraulic control | ||
| Wrapping Options | Net only | Net only | Duckbill net feeding, edge to edge | |
| Net Storage | 3 net rolls (without twine); 6 twine rolls active | 1 active + 2 spare rolls | ||
| Monitor & Tyres | ||||
| Baler Control System | ISOBUS system, ships with AFS Pro 300 | AFS Pro 700 | ||
| Tyres | 500/55-20 | |||
| Brakes | Pneumatic or hydraulic (optional)* | Hydraulic or pneumatic | ||
| Dimensions & Weight | ||||
| Total Length | – | 4,865 mm | 5,120 mm | |
| Total Height | – | 3,170 mm | 3,280 mm | |
| Width (500/55-20 tyres) | – | 2,742 mm | ||
| Weight | – | 3,500 kg | 3,850–4,235 kg (Feeder/Cutter) |
