New Holland T4 F/N/V
75 – 120 hp | 4WD / SuperSteer™ | Shuttle Command™ / Dual Command™ Transmission
Looking for a specialist tractor range that can handle orchards, vineyards and narrow rows with ease? The New Holland T4 F/N/V range spans five power tiers from 75 to 120hp, powered by proven FPT F34 and F36 Stage V engines, backed by high capacity hydraulics, a rear lift capacity of up to 2,520kg and the legendary SuperSteer™ front axle for a turning radius as low as 2.9m. Designed and built for specialist crops, it's built to handle spraying, mowing, harvesting and general orchard work all day, every day, in the tightest of rows – with Vineyard (V), Narrow (N) and Fruit (F) width configurations to suit every row spacing.
Why Growers Choose the T4 F/N/V
| SuperSteer™ Agility
An effective steering angle of up to 76° delivers a turning radius as low as 2.9m, so no time is lost at the headland. | VisionView™ Cab
A high visibility front windscreen and 4-pillar design give a 360° view, so front-mounted implements are always easy to see and control. | Blue Cab™ 4 Filtration
Optional category 4 double filtration system protects the operator against dust, aerosols and vapours during spraying operations. |
| Real Flat Deck
A genuine flat operator deck with no central tunnel gives wide, easy access and more room for the operator's feet all day long. | Lift-O-Matic™ Plus
Award winning mechanical hydraulic control lets you raise or lower the rear linkage at the headland while keeping position and draft settings. | A Model for Every Row
Five power tiers from 75 to 120hp, each available in Vineyard, Narrow and Fruit widths, so there's a T4 for every specialist operation. |
T4 F/N/V Specifications
| MODEL | |||||
| Model | T4.80 | T4.90 | T4.100 | T4.110 | T4.120 |
| ENGINE | |||||
| Engine model / make | F34, FPT | F36, FPT | |||
| Cylinders / capacity / valves | 4 / 3,400 cm³ / 2 | 4 / 3,600 cm³ / 4 | |||
| Emissions level | Stage V | ||||
| Rated engine power (ISO TR14396 - ECE R120) | 55 kW / 75 hp | 63 kW / 86 hp | 73 kW / 99 hp | 81 kW / 110 hp | 88 kW / 120 hp |
| Max. power @ 1,900 rpm | 55 kW / 76 hp | 63 kW / 87 hp | 73 kW / 100 hp | 81 kW / 111 hp | 88 kW / 121 hp |
| Rated engine speed | 2,300 rpm | ||||
| Max. torque @ 1,300 rpm | 320 Nm | 351 Nm | 407 Nm | 490 Nm | 518 Nm |
| Torque reserve | 40% | 34% | 34% | 46% | 42% |
| Fuel tank capacity (4WD / SuperSteer™) | 58 / 73 L | ||||
| AdBlue tank capacity | 11 L | ||||
| Service interval | 600 hours | ||||
| TRANSMISSION | |||||
| 16x16 Shuttle Command™ (40kph) – min. speed 0.7 kph | Standard | ||||
| 28x16 Shuttle Command™ with Creeper – min. speed 0.17 kph | Optional | ||||
| 32x16 Split Command™ (40kph) | Optional | ||||
| 32x16 Dual Command™ with Powerclutch (40kph) | Optional | ||||
| 44x16 Dual Command™ with Creeper – min. speed 0.30 kph | Optional | ||||
| Electro-hydraulic differential lock | Standard | ||||
| FRONT AXLE | |||||
| 4WD front axle | Standard | ||||
| SuperSteer™ 4WD front axle | Standard on N/F | ||||
| Terraglide™ front axle suspension | Optional | ||||
| Turning angle (4WD / SuperSteer™) | 55° / 76° | ||||
| Turning radius (SuperSteer™) | As low as 2.9 m | ||||
| HYDRAULICS | |||||
| Standard pump flow + service pump | 64 + 36 Lpm | ||||
| Optional MegaFlow™ pump flow + service pump | 80 + 36 Lpm | ||||
| Mechanical Draft Control with Lift-O-Matic™ Plus | Standard | ||||
| Max. no. rear remote valves / outlets | 3+2 / 10 | ||||
| Max. mid-mounted outlets | 4 | ||||
| LINKAGE | |||||
| Max. rear lift capacity at ball ends | 2,200 kg | 2,200 kg | 2,520 kg | 2,520 kg | 2,520 kg |
| Max. front linkage lift capacity at ball ends | 1,500 kg (Optional) | ||||
| PTO | |||||
| Rear PTO speeds | 540 / 540E rpm (Standard) | ||||
| 1000 rpm and ground speed PTO | Optional | ||||
| Front lift & PTO (1000rpm electro-hydraulic dry clutch) | Optional | ||||
| OPERATOR ENVIRONMENT | |||||
| VisionView™ cab with flat deck | Standard | ||||
| In-cab noise level | 71 dB(A) | ||||
| Blue Cab™ 4 filtration (category 4) | Optional | ||||
| LED lighting pack (up to 8 working lights) | Optional | ||||
| DIMENSIONS & WEIGHT | |||||
| Minimum overall width (N) | 1,229 mm | ||||
| Height from rear axle to top of cab | 1,011 mm | ||||
