New Holland T5 Dual Command Series
New Holland T5.100 Dual Command
The T5.100 Dual Command pairs the latest 101hp FPT F5 4-cylinder engine (ECOBlue™ Compact HI-eSCR 2, Stage V) with a smooth 24x24 Dual Command™ transmission and electronic power shuttle – the ideal all-rounder for tillage, seeding, spraying and loader work.
A Deluxe VisionView™ cab with air suspension seat, air conditioning and a new U-shape exhaust for clearer forward visibility keeps operators comfortable all day, while the integrated loader joystick and Dynamic Start-Stop feature make front-end loader work faster and safer.
New Holland T5.120 Dual Command
The T5.120 Dual Command pairs the latest 117hp FPT F5 4-cylinder engine (ECOBlue™ Compact HI-eSCR 2, Stage V) with a smooth 24x24 Dual Command™ transmission and electronic power shuttle – the ideal all-rounder for tillage, seeding, spraying and heavier loader work.
A Deluxe VisionView™ cab with air suspension seat, air conditioning and a new U-shape exhaust for clearer forward visibility keeps operators comfortable all day, while the integrated loader joystick and Dynamic Start-Stop feature make front-end loader work faster and safer.
New Holland T5.95 Dual Command
The T5.95 pairs a Tier 4A FPT F5C 3.4L 4-cylinder engine (99hp, 407Nm) with a 24x24 Dual Command™ transmission featuring a Hi-Lo powershift splitter and PowerClutch – an outstanding all-rounder for loader work, front or rear implements and everyday road transport.
The spacious Deluxe VisionView™ cab offers outstanding all-round visibility with a high visibility roof hatch, deluxe air suspension seat and CommandArc control layout, while a 600-hour service interval and ground-level service points keep operators comfortable and minimise downtime.
New Holland T5.105 Dual Command
Complete. Compact. Competitive.
The T5.105 pairs a Tier 4A FPT F5C 3.4L 4-cylinder engine (107hp, 444Nm) with a 24x24 Dual Command™ transmission featuring a Hi-Lo powershift splitter and PowerClutch – an outstanding all-rounder for loader work, front or rear implements and everyday road transport.
The spacious Deluxe VisionView™ cab offers outstanding all-round visibility with a high visibility roof hatch, deluxe air suspension seat and CommandArc control layout, while a 600-hour service interval and ground-level service points keep operators comfortable and minimise downtime.
| Transmission Family | Electro Command™ (Semi-Powershift) | Dual Command™ (Current) | Dual Command™ (MY24) | Auto Command™ (CVT) | |||||
|---|---|---|---|---|---|---|---|---|---|
| Model | T5.90S | T5.100S | T5.110S | T5.100 | T5.120 | T5.95 | T5.105 | T5.120 | T5.140 |
| Engine | |||||||||
| Engine / Emissions | S8000, Tier III | FPT F5, Stage V | FPT F5C, Tier 4A | FPT, Stage V (EGR Free) | |||||
| Capacity | 3.9 L | 3,600 cm³ | 3,400 cm³ | 4,485 cm³ | |||||
| Max Power | 88 hp | 98 hp | 110 hp | 101 hp | 117 hp | 99 hp | 107 hp | 120 hp | 140 hp |
| Max Torque | 358 Nm | 390 Nm | 430 Nm | 450 Nm | 506 Nm | 407 Nm | 444 Nm | 551 Nm | 630 Nm |
| Fuel Tank | 155 L | 130 L | 160 L | 180 L + 19 L AdBlue | |||||
| Transmission | |||||||||
| Type | 16x16 Semi-Powershift (40kph) | 24x24 Dual Command™ (40kph) | CVT, fully automatic | ||||||
| Speed Range | Up to 40 kph | Up to 40 kph | 0.02 – 40 kph | ||||||
| Hydraulics & Linkage | |||||||||
| Main Pump Flow | 84 L/min | 64 / 82 L/min | 64 L/min | 113 L/min | |||||
| Max Rear Lift Capacity | 5,200 kg | 4,700 kg | 4,400 kg | 5,500 kg | |||||
| Front Linkage Lift Capacity | – | 1,670 kg | 1,700 kg | 2,250 kg | |||||
| PTO | |||||||||
| Rear PTO Speeds | 540 / 540E / 1000 rpm | ||||||||
| Dimensions & Weight | |||||||||
| Wheelbase | 2,519 mm | 2,350 mm | 2,285 mm | 2,490 mm | |||||
| Overall Length | 4,496 mm | 3,981 mm | 4,036 mm | 4,397 mm | |||||
| Weight (min. / shipping) | 4,220 kg | 4,100 kg | – | 3,700 kg |
