New Holland T6 Series
New Holland T6.145
Engineered by design to meet your needs.
The New Holland T6.145 is the entry point to the fully customisable T6 range, powered by a Stage V ECOBlue™ HI-eSCR 2 4-cylinder FPT engine delivering a maximum 145hp (with EPM). Available with the new 8-step Dynamic Command™ semi-powershift or the renowned Auto Command™ CVT, it's designed for modern mixed arable farmers and intensive livestock operations – and independently verified as the most efficient in its segment with 9% lower fuel consumption.
The industry-leading Horizon™ cab keeps noise to a whisper-quiet 69dB(A), with award-winning SideWinder™ II armrest ergonomics, up to 16 LED work lights and a range of Dynamic Comfort and Auto Comfort™ seats – delivering all-day comfort for the longest working days.
New Holland T6.165
More power in reserve when the work gets heavy.
The New Holland T6.165 steps up the 4-cylinder T6 range, powered by a Stage V ECOBlue™ HI-eSCR 2 FPT engine delivering a maximum 169hp (with EPM) – and up to 34 extra horsepower on tap through Engine Power Management when the going gets tough. Available with the new 8-step Dynamic Command™ semi-powershift or the renowned Auto Command™ CVT, it delivers exceptional productivity with class-leading fuel efficiency.
The industry-leading Horizon™ cab keeps noise to a whisper-quiet 69dB(A), with the award-winning SideWinder™ II armrest and CommandGrip™ handle fitted as standard, up to 16 LED work lights and a range of Dynamic Comfort and Auto Comfort™ seats for all-day comfort.
New Holland T6.180
The range-topping 6-cylinder T6.
The New Holland T6.180 crowns the T6 range with a smooth Stage V ECOBlue™ HI-eSCR 2 6-cylinder FPT engine delivering a maximum 175hp (with EPM). Now available with either the 8-step Dynamic Command™ semi-powershift or the renowned Auto Command™ CVT, its extra cylinder brings refinement and torque for demanding mixed farming, baling and heavy transport work – with a power-to-weight ratio ideal for a full range of applications.
The industry-leading Horizon™ cab keeps noise to a whisper-quiet 69dB(A), with award-winning SideWinder™ II armrest ergonomics, up to 16 LED work lights and a range of Dynamic Comfort and Auto Comfort™ seats – and the option of the luxury Blue Power edition for the ultimate in premium farming.
| Model | New Holland T6.145 | New Holland T6.165 | New Holland T6.180 |
|---|---|---|---|
| Engine | |||
| Cylinders / Capacity | 4-cyl / 4,485 cm³ | 4-cyl / 4,485 cm³ | 6-cyl / 6,728 cm³ |
| Emissions | Stage V ECOBlue™ HI-eSCR 2 | ||
| Rated Power | 116 hp | 135 hp | 150 hp |
| Max Power (with EPM) | 145 hp | 169 hp | 175 hp |
| Max Torque (with EPM) | 528 Nm (590 EPM) | 605 Nm (700 EPM) | 650 Nm (738 EPM) |
| Diesel / AdBlue Tank | 218 L (263 L wide) / 31 L AdBlue | ||
| Service Interval | 750 hours | ||
| Transmission | |||
| Options | Dynamic Command™ 8-step semi-powershift (24x24) OR Auto Command™ CVT | ||
| Top Speed | 40 kph / 40 ECO / 50 kph ECO | ||
| CVT Speed Range | 0.02 – 50 kph (Auto Command) | ||
| Hydraulics & Linkage | |||
| CCLS Main Pump | 150 L/min @ 210 bar (86 L/min fixed displacement standard) | ||
| Steering / Services Pump | 47 L/min (67 L/min optional) | ||
| Max Rear Lift Capacity | 7,864 kg (at ball ends) | ||
| Front Linkage Lift Capacity | 3,200 kg | ||
| PTO | |||
| Rear PTO Speeds | 540 / 540E / 1000 | 540 / 540E / 1000 | 540 / 540E / 1000 / 1000E |
| Dimensions & Weight | |||
| Wheelbase | 2,642 mm | ||
| Overall Length | 5,189 mm | ||
| Turning Radius | 4,600 mm | ||
| Min. Shipping Weight | 5,430 kg | 5,740 kg | 5,610 kg |
| Max Permissible Weight | 10,500 kg |
