New Holland T6000 Series
New Holland T6020
A nimble all-rounder that pulls its weight at haulout.
The New Holland T6020 is the compact, agile workhorse of the T6000 range, powered by a fuel-efficient NEF 4-cylinder engine delivering 112hp (up to 142hp with EPM on Plus models). With high torque available at low engine speeds, it's ideally suited to cane haulout and bin work – while still switching effortlessly between paddock, livestock and general transport jobs.
The industry-leading 360° Horizon™ cab offers 5.87m² of glass for perfect all-round visibility, deluxe air-suspension seating and fingertip controls to keep operators fresh through long haulout shifts – while the semi-powershift Electro Command™ transmission with memory shuttle and CCLS hydraulics deliver clutchless shifting and smooth, repeatable cycles in the paddock and on the headland.
New Holland T6070
Serious haulout power for the toughest seasons.
The New Holland T6070 is the range-topping T6000 and a genuine haulout heavyweight, powered by a fuel-efficient NEF 6-cylinder engine delivering 141hp – and up to 178hp with Engine Power Management (EPM) for demanding transport and full bins. With up to 678Nm of torque and an optional 50kph direct-drive top speed, it moves loads quickly between paddock and siding while keeping fuel consumption in check.
Built for the long days of harvest, the New Holland T6070 pairs Terraglide™ front axle suspension and Comfort Ride™ cab suspension for a smooth, low-fatigue ride on rough haulout tracks and road runs – while the 360° Horizon™ cab, Electro Command™ transmission and Auto Transport mode take the effort out of repetitive shuttle work.
New Holland T6080
The heavy hitter for serious haulout and drawbar work.
The New Holland T6080 sits at the top of the T6000 family, powered by a 6.7L 6-cylinder Tier III FPT engine delivering a rated 155hp. With a full-powershift Range Command transmission, heavy-duty axles and a 50kph transport option, it's a genuine haulout workhorse – built to move full bins quickly between paddock and siding, season after season.
Backed by a big 113 L/min hydraulic pump with a separate 65 L/min steering supply and a 5,812kg rear lift capacity, the T6080 handles the heaviest implements with ease. A deluxe air-suspension seat, instructor's seat, and 8 halogen work lights keep operators comfortable and productive through the longest harvest days.
| Model | New Holland T6020 | New Holland T6070 | New Holland T6080 |
|---|---|---|---|
| Engine | |||
| Engine | NEF 4-cyl, 4.5 L, Tier III | NEF 6-cyl, 6.7 L, Tier III | FPT 6-cyl, 6.7 L, Tier III |
| Rated Power | 112 hp | 141 hp | 155 hp |
| Max Power (with EPM) | Up to 142 hp (Plus) | Up to 178 hp (Elite) | 155 hp |
| Max Torque | 520 Nm (550 w/ EPM) | 625 Nm (678 w/ EPM) | – |
| Service Interval | 600 hrs engine / 1,200 hrs transmission | ||
| Transmission | |||
| Type | Electro Command™ 16x16 semi-powershift | 18x6 full powershift / Range Command | |
| Top Speed | 40 kph (50 kph optional) | ||
| Hydraulics & Linkage | |||
| Main Pump Flow | 113 L/min (CCLS) | ||
| Steering Pump | 47 L/min | 65 L/min | |
| Max Rear Lift Capacity | 7,864 kg (at ball ends) | 5,812 kg (610mm behind balls) | |
| Axles | |||
| Front Axle Options | 4WD standard, SuperSteer™ / Terraglide™ optional | HD Standard / Suspended / SuperSteer™ | |
| Rear Axle | Bar or flange type | HD Bar or flange type | |
| PTO | |||
| Rear PTO Speeds | 540 / 540E / 1000 rpm | ||
| Fuel & Weight | |||
| Fuel Tank | 176 L | 250 L | – |
| Max Permissible Weight | 9,000 kg | – |
