New Holland T9 Series

New Holland T9.470

More of everything – just what you asked for.
The New Holland T9.470 opens the articulated 4WD T9 Series, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine delivering a rated 425hp and a peak 467hp. Built on New Holland's rugged articulated tri-point chassis for maximum pulling power and fuel efficiency, it's available in row crop narrow-frame or heavy-duty wheeled configurations with a choice of Ultra Command™ powershift or Auto Command™ CVT.

The premium cab features exclusive four-point Comfort Ride™ suspension, the SideWinder™ Ultra armrest and IntelliView™ 12 touchscreen – while up to 88.1 sq ft of glass, enhanced LED lighting packages and full FieldOps™ connectivity keep you comfortable, visible and connected through the biggest jobs.

Key Specifications

Engine	FPT Cursor 13, 6-cylinder, 12.9L, eVGT • 425 hp rated @ 2,100 rpm • 467 hp peak @ 1,900 rpm • 40% torque rise • 1,170L fuel capacity
Transmission	Ultra Command™ 16F/2R powershift (40kph) with Ground Speed Management • OR optional Auto Command™ CVT (40kph)
Hydraulics & Lift	Main pump: 159 L/min (216 L/min high flow) • Optional MegaFlow™ II: up to 428 L/min • Max. lift capacity: 9,071 kg
PTO	Optional 1000-rpm, 20-spline PTO • CAT 4 / CAT 5 drawbar options

New Holland T9.520

Precision meets serious pulling power.
The New Holland T9.520 steps up the articulated 4WD T9 Series, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine delivering a rated 475hp and up to 522hp maximum. Built on New Holland's rugged articulated tri-point chassis for maximum pulling power and fuel efficiency, it's available in row crop narrow-frame or heavy-duty wheeled configurations with a choice of Ultra Command™ powershift or Auto Command™ CVT.

Key Specifications

Engine	FPT Cursor 13, 6-cylinder, 12.9L, eVGT • 475 hp rated • Up to 522 hp max • 462 hp PTO • 1,173L fuel capacity (159L DEF)
Transmission	Ultra Command™ 17F/2R full powershift (40kph) • OR optional Auto Command™ CVT (40kph)
Hydraulics & Lift	Main pump: 159 L/min • Optional MegaFlow™ II: up to 428 L/min • Max. rear lift capacity: 9,935 kg
PTO	1000-rpm independent rear PTO • CAT 4 / CAT 5 drawbar options

Get a quote View Brochure

New Holland T9.580

The top of the row-crop line, built to lead.
The New Holland T9.580 tops the row-crop T9 models, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine delivering a rated 525hp and a peak 578hp. Built on New Holland's rugged articulated tri-point chassis for maximum pulling power and fuel efficiency, it's available in row crop narrow-frame or heavy-duty wheeled configurations with a choice of Ultra Command™ powershift or Auto Command™ CVT.

Key Specifications

Engine	FPT Cursor 13, 6-cylinder, 12.9L, eVGT • 525 hp rated @ 2,100 rpm • 578 hp peak @ 1,900 rpm • 40% torque rise • 1,170L fuel capacity
Transmission	Ultra Command™ 16F/2R powershift (40kph) with Ground Speed Management • OR optional Auto Command™ CVT (40kph)
Hydraulics & Lift	Main pump: 159 L/min (216 L/min high flow) • Optional MegaFlow™ II: up to 428 L/min • Max. lift capacity: 9,071 kg
PTO	Optional 1000-rpm, 20-spline PTO • CAT 4 / CAT 5 drawbar options

New Holland T9.615

Wide-frame muscle for the biggest paddocks.
The New Holland T9.615 opens the high-power wide-frame T9 models, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine with two-stage turbocharging, delivering a rated 555hp and a peak 614hp. Built on New Holland's rugged articulated tri-point chassis with heavy-duty axles, it's available in wide-frame Ag or factory scraper-ready configurations with a choice of Ultra Command™ powershift or Auto Command™ CVT.

Key Specifications

Engine	FPT Cursor 13 Two-stage Turbo, 6-cylinder, 12.9L • 555 hp rated @ 2,100 rpm • 614 hp peak @ 1,900 rpm • 40% torque rise • 1,666L fuel capacity
Transmission	Ultra Command™ 16F/2R powershift (40kph) with Ground Speed Management • OR optional Auto Command™ CVT (40kph)
Hydraulics & Lift	Main pump: 159 L/min (216 L/min high flow) • Optional MegaFlow™ II: up to 428 L/min • Max. lift capacity: 10,319 kg
PTO	Optional 1000-rpm, 20-spline PTO • CAT 4 / CAT 5 drawbar • Factory scraper-ready option

New Holland T9.655

Built heavier, built to pull harder.
The New Holland T9.655 steps up the high-power wide-frame T9 models, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine with two-stage turbocharging, delivering a rated 595hp and a peak 656hp. Built on New Holland's rugged articulated tri-point chassis with the largest heavy-duty axles, it's available in wide-frame Ag or factory scraper-ready configurations with the rugged Ultra Command™ powershift transmission.

Key Specifications

Engine	FPT Cursor 13 Two-stage Turbo, 6-cylinder, 12.9L • 595 hp rated @ 2,100 rpm • 656 hp peak @ 1,900 rpm • 40% torque rise • 1,666L fuel capacity
Transmission	Ultra Command™ 16F/2R powershift only (40kph) with Ground Speed Management – Auto Command™ CVT not available
Hydraulics & Lift	Main pump: 159 L/min (216 L/min high flow) • Optional MegaFlow™ II: up to 428 L/min • Max. lift capacity: 10,319 kg
PTO	Optional 1000-rpm, 20-spline PTO • CAT 4 / CAT 5 drawbar • Factory scraper-ready option

New Holland T9.700

More of everything – just what you asked for.
The New Holland T9.700 crowns the T9 Series as the flagship 4WD, powered by the proven 12.9L FPT Cursor 13 6-cylinder engine with two-stage turbocharging, delivering a rated 645hp and a peak 699hp. Built on New Holland's rugged articulated tri-point chassis with the largest heavy-duty axles, it's available in wide-frame Ag or factory scraper-ready configurations with the rugged Ultra Command™ powershift transmission – the ultimate machine for the biggest broadacre and earthmoving jobs.

Key Specifications

Engine	FPT Cursor 13 Two-stage Turbo, 6-cylinder, 12.9L • 645 hp rated @ 2,100 rpm • 699 hp peak @ 1,900 rpm • 40% torque rise • 1,666L fuel capacity
Transmission	Ultra Command™ 16F/2R powershift only (40kph) with Ground Speed Management – Auto Command™ CVT not available
Hydraulics & Lift	Main pump: 159 L/min (216 L/min high flow) • Optional MegaFlow™ II: up to 428 L/min • Max. lift capacity: 10,319 kg
PTO	Optional 1000-rpm, 20-spline PTO • CAT 4 / CAT 5 drawbar • Factory scraper-ready option

⬅ Swipe sideways to compare models ➡

Model	T9.470	T9.520	T9.580	T9.615	T9.655	T9.700
Engine
Engine	FPT Cursor 13, 12.9L (eVGT single-stage)	FPT Cursor 13, 12.9L (two-stage turbo)
Rated Power	425 hp	475 hp	525 hp	555 hp	595 hp	645 hp
Peak Power	467 hp	522 hp	578 hp	614 hp	656 hp	699 hp
PTO Power	409 hp	462 hp	516 hp	537 hp
Fuel Capacity	1,170 L	1,666 L
Transmission
Ultra Command™ Powershift	Standard — 16F/2R (40 kph) with Ground Speed Management
Auto Command™ CVT	Optional	Optional	Optional	Optional	–	–
Axles & Hydraulics
Axle Diameter	127 mm (5.0 in) bar	140 mm (5.5 in) bar
Main Pump Flow	159 L/min (216 L/min high flow) — MegaFlow™ II up to 428 L/min
Hitch Lift Capacity	9,071 kg	10,319 kg
Scraper-Ready Option	–	–	–	Available	Available	Available
Dimensions & Weight
Wheelbase	3,759 mm	3,911 mm
Base Shipping Weight	18,507 kg	21,012 kg	22,828 kg
Max GVW	25,401 kg	27,215 kg	30,391 kg
