New Holland TD5S Series
New Holland TD5.90
The New Holland TD5.90 combines segment-leading operator comfort with proven, robust technology in a stunningly styled traditional tractor. Powered by a rugged 4-cylinder turbocharged intercooled Tier III engine producing 88 hp and 356 Nm of torque, it delivers reliable performance backed by strong hydraulics and an impressive 3,565 kg lift capacity.
New Holland TD5.100
The New Holland TD5.100 combines segment-leading operator comfort with proven, robust technology in a stunningly styled traditional tractor. Powered by a rugged 4-cylinder turbocharged intercooled Tier III engine producing 98 hp and 390 Nm of torque, it delivers reliable performance backed by strong hydraulics and an impressive 3,565 kg lift capacity.
New Holland TD5.110
Topping the range, the New Holland TD5.110 combines segment-leading operator comfort with proven, robust technology in a stunningly styled traditional tractor. Powered by a rugged 4-cylinder turbocharged intercooled Tier III engine producing 110 hp and 430 Nm of torque, it delivers reliable performance backed by strong hydraulics and an impressive 3,565 kg lift capacity.
| Model | TD5.90 | TD5.100 | TD5.110 |
|---|---|---|---|
| Engine | |||
| Rated Power | 65 kW (88 hp) | 73 kW (98 hp) | 81 kW (110 hp) |
| Cylinders / Capacity | 4-cyl, 3.9 L, Turbocharged Intercooled | ||
| Emissions | Tier III (B100 biodiesel approved) | ||
| Max Torque | 356 Nm @ 1,400 rpm | 390 Nm @ 1,400 rpm | 430 Nm @ 1,400 rpm |
| Torque Rise | 33% | 30% | 30% |
| Fuel Tank | 110 L | ||
| Service Interval | 300 hrs | ||
| Power Take Off | |||
| PTO Power | 60 kW (82 hp) | 67 kW (92 hp) | 76 kW (104 hp) |
| PTO Speeds | 540 / 540E rpm (optional 540/1,000 with ground speed) | ||
| Transmission | |||
| Standard | 12 x 12 Hydraulic Powershuttle | ||
| Optional | 20 x 12 SynchroShuttle with creeper | ||
| Min/Max Road Speed | 1.82–30.1 km/h (0.33–30.1 km/h with creeper) | ||
| Axle & Steering | |||
| Steering Angle (4WD) | 55° | ||
| Min Turning Radius | 5,500 mm | 5,510 mm | 5,580 mm |
| Hydraulics | |||
| Main Pump Flow | 51.7 L/min @ 198 bar | ||
| Steering Pump Flow | 29.6 L/min @ 170 bar | ||
| Rear Remote Valves | 2 standard, 3 max | ||
| 3-Point Linkage | |||
| Category | I / II | ||
| Lift Capacity @ Ball Ends | 3,565 kg | ||
| Lift @ 610mm Behind Ball Ends | 2,700 kg | ||
| Dimensions & Weight | |||
| Overall Length (4WD) | 4,044 mm | 4,115 mm | 4,115 mm |
| Width Across Fenders | 1,910 mm | ||
| Height to Top of Cab | 2,604 / 2,719 mm | 2,604 / 2,719 mm | 2,657 / 2,772 mm |
| Ground Clearance (Axle/Drawbar) | 425 / 450 mm | 465 / 470 mm | 465 / 500 mm |
| Track Width (Min/Max) | 1,500–2,000 mm | ||
| Rear Tyres | 18.4R34 | 18.4R34 | 16.9R38 |
| Minimum Weight (Cab/ROPS) | 3,700 / 3,450 kg | 3,900 / 3,650 kg | 3,900 / 3,650 kg |
