New Holland TT3.50 Series
New Holland TT3.50
50 hp | 2WD / 4WD | 8x8 Synchro Shuttle™ Transmission
Looking for a no-nonsense, budget-friendly tractor that can still handle real farm work? The New Holland TT3.50 delivers 50hp from a productive 2.9L three-cylinder FPT engine, backed by high capacity hydraulics, a heavy duty rear axle and a rear linkage lift capacity of up to 1,800kg. Designed and proven for the Australian market, it's built to handle loader work, slashing and general property jobs all day, every day.
Why Farmers Choose the TT3.50
| Loader Ready
Higher load-rated front tyres and a heavy duty front axle allow a larger New Holland APs30 loader kit to be fitted. | High Capacity Hydraulics
38 L/min main pump flow with an independent steering circuit, so you can steer and operate implements at the same time with no loss in performance. | Reliable Transmission
Standard 8x8 mechanical Synchro Shuttle™ transmission with a beefy 11" clutch, built for heavy duty loader applications. |
| Operator Comfort
Redesigned suspension seat, flip-up armrests and a semi-flat platform give you more room and less fatigue over a long day. | Heavy Duty Axles
Oil Immersed Disc Brakes (OIDB) on the rear axle and a 4,000kg restricted front axle capacity that tops its class. | Easy Maintenance
Single piece hood opens wide with gas-strut assist, and all service points are accessible from the ground without tools. |
TT3.50 Specifications
| MODEL | |
| Model | TT3.50 |
| ENGINE | |
| Engine model / make | S8000, FPT |
| Cylinders / aspiration / valves / emission level | 3 / NA / 2 / Tier 2 |
| Capacity | 2.9 L |
| Max power | 37.6 kW / 50.5 hp |
| Net advertised power @ 2,100 rpm | 36.9 kW / 49.5 hp |
| PTO power at rated speed | 33.6 kW / 45 hp |
| Max. torque @ 1,300 rpm | 205 Nm |
| Fuel tank capacity | 60 L |
| TRANSMISSION & CLUTCH | |
| Double clutch | Standard |
| 8x8 mechanical Synchro Shuttle™ transmission | Optional |
| Minimum / maximum road speed | 2.75 / 33.95 km/h |
| FRONT AXLES | |
| 2WD front axle | Optional |
| 4WD front axle | Standard |
| Turning radius 2WD (with / without brakes) | 3,200 / 3,520 mm |
| Turning radius 4WD (with / without brakes) | 3,670 / 5,225 mm |
| REAR AXLE | |
| Planetary reduction final drive | Standard |
| Differential lock (mechanically engaged) | Standard |
| Oil immersed multidisc braking system | Standard |
| HYDRAULICS | |
| Main pump flow / pump pressure | 38 Lpm / 210 Bar |
| Independent steering pump flow / pump pressure | 24 Lpm / 210 Bar |
| Rear remote valves (max. number) | 2 (Optional) |
| LINKAGE | |
| Category | I-II |
| Lift capacity @ ball ends | 1,800 kg |
| Max. lift capacity @ 610mm behind ball ends | 1,440 kg |
| PTO | |
| Independent rear PTO | 540 / 540E |
| Rear PTO speed | 540 rpm |
| Rear PTO engine speed @ 540 rpm | 2,016 rpm |
| Rear PTO engine speed @ 540E rpm | 1,590 rpm |
| OPERATOR ENVIRONMENT | |
| Semi flat deck operator area | Standard |
| Deluxe operator seat with armrest and seatbelt | Standard |
| Two post fixed ROPS with canopy | Standard |
| ELECTRICALS | |
| Battery | 100 Ah |
| Alternator rating | 55 Amp |
| TYRES | |
| Front (2WD) | 7.50 x 16 (Optional) |
| Front (Ag - std. axle) | 9.5 x 24 (Standard) |
| Rear (Ag) | 14.9 x 28 (Standard) |
| DIMENSIONS & WEIGHT | |
